※ FTY-A15 / A21  Line Boring Machine Specifications Model FTY-A15 FTY-A21 Motor 2HP 2.5HP Table size 480 x 1200mm Max. drilling depth 75mm Max. Distance between center 32mm Compress air required 6-8kg/cm2 Number of spindle per boring head 15 21 N.W. , G.W. 140/190 kgs 150/200 kgs Machine size 1200 x 700 x 1520mm Packing size 1397 x 838 x 1778mm

Fantastic Machinery Co., Ltd.

TEL.: + 886 4 25123889  FAX: + 886 4 25122898

Email: heather.ko1688@msa.hinet.net
